Which hydraulic cylinder series should I choose?

For standard industrial motion up to 160 bar choose CD / DK (ISO 6020/2). For long strokes and higher loads at 210 bar the flange HD / HK are suitable. For the toughest duty up to 250 bar, the DP series (ISO 6022). For limited space the compact RP / MP / RQ, and for precise continuous positioning the TD / TK / TH / TX / TP servo cylinders. The online configurator works out the specific type from force, stroke and speed.

What is the difference between ISO 6020/2 and ISO 6022?

ISO 6020/2 defines medium-duty cylinders with an operating pressure of 160 bar (tie-rod CD/DK) up to 210 bar (flange HD/HK). ISO 6022 is the standard for higher-strength cylinders with an operating pressure of 250 bar (the DP/TP series). Both standards standardise the connection and mounting dimensions, so the cylinders are dimensionally interchangeable between manufacturers.

Are Conforti cylinders interchangeable with Parker Hannifin or Bosch Rexroth?

Yes. Thanks to compliance with ISO 6020/2 and ISO 6022, Conforti cylinders have standardised connection and mounting dimensions. In most cases they can be used as a replacement for Parker Hannifin, Bosch Rexroth and other manufacturers’ cylinders with no machine modifications. To be sure, we recommend comparing the SKU and mounting in the configurator, or sending us the parameters of the original cylinder.

How long does delivery of a custom hydraulic cylinder take?

We handle standard orders within 14 working days. In urgent cases we offer express delivery of selected configurations within 48 hours. We confirm the exact date in the quotation, which we usually send within one working day of receiving the enquiry.

Can I download a 2D drawing or a 3D CAD model of the cylinder?

Yes, free of charge. After assembling the cylinder code (SKU) in the configurator, enter the code into the Code Wizard and download the exact model in STEP, IGES, DWG, Parasolid, STL, DXF or PDF format. The model matches your configuration exactly.

Which countries do you supply Conforti hydraulic cylinders to?

As the authorised distributor of Conforti Oleodinamica we supply the Czech Republic, Slovakia and other EU countries. Enquiries can be sent online; we prepare the quotation with the specific country of delivery and currency in mind.

Why buy hydraulic cylinders directly from hydraulika.store?

We are the authorised distributor of Conforti Oleodinamica for the Czech Republic, Slovakia and the EU, supplying directly from the manufacturer, who holds both cylinders and components in stock — which lets us offer highly competitive prices with no middlemen and short lead times (standard variants within 14 working days, special ones within 20 days, urgent ones even within 48 hours once feasibility is confirmed). We focus purely on B2B — manufacturing plants, toolrooms, maintenance and service in the form of spare parts (seals, flanges, rods and other components), thanks to which maintenance in continuous operation does not mean replacing the whole cylinder.

Industrial hydraulic cylinders ready for your operation

We help companies in automotive, toolrooms, rolling mills and forming machines, the pharmaceutical industry and automation solve the problem of long lead times. Conventional double-acting cylinders as well as special variants — nickel-plated, with a position sensor, with Viton seals.

We save design engineers time — 3D CAD models of the cylinders are available immediately.

Delivery within 48 h

ISO 6020/2 & ISO 6022

Replacement without machine changes

Open the cylinder configurator

Standard
Pressure
Bore
Design

160–250 bar

operating pressure

Ø 25–200 mm

bore diameter

14+

ISO mounting types

48 h

express delivery

100%

inspected before dispatch

ISO 6020/2 & ISO 6022

Choose a cylinder in 3 steps

Answer 2–3 questions — the recommended series is recalculated instantly. The configurator works out the specific type from force, stroke and speed.

ISO / Compact

Step 01

Step 02

Recommended series

Standard
Pressure
Bore

Go to the series → Configurator

Product series

Choose a hydraulic cylinder series

Industrial ISO cylinders, compact cylinders and servo cylinders for precise positioning. Every series is available as a 3D CAD model to download.

Quick comparison

Which cylinder series is right for you?

Standard, operating pressure, bore and maximum stroke of every Conforti series. Values per the Conforti Oleodinamica catalogue.

Series	Standard / type	Pressure	Bore	Max. stroke	Typical use

* On the compact RP / MP series the maximum pressure for Ø 80 and Ø 100 mm is 100 bar (the limit of the aluminium alloy). The standard stroke of compact cylinders is 100 mm, custom strokes on request. Check the maximum stroke and other variants in the online configurator.

From dispatch

Conforti cylinders in detail

Precise workmanship, accessory assembly and quality control — a look at the technical precision and rugged build.

Why Conforti

Why choose Conforti hydraulic cylinders?

We size Conforti hydraulic cylinders to your application — advising on the series, bore, stroke, mounting and seal type. From automation and clamping fixtures through presses and injection moulding machines to forming and rolling mills, you get a reliable double-acting hydraulic cylinder that fits your machine exactly.

Manufactured to ISO100 % inspectedFree CAD

Where we work

Typical industrial applications

We supply Conforti hydraulic cylinders to dozens of types of industrial plant in the Czech Republic, Slovakia and the EU.

Frequently asked questions

Answers about choosing a series, lead times, CAD data and the compatibility of Conforti cylinders.

Didn’t find your answer?

We usually send a quotation within one working day.

Open the configurator → poptavky@hydraulika.store
